Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L®

Entry Level, Cost Effective Server. Compact, less than 15" Depth. 4x GbE LAN ports, 1x dedicated IPMI LAN.

  • Entry level, Cost effective
  • Compact, less than 15" depth
  • Single Socket H4 (LGA 1151) supports Intel Xeon processor E-2100, 8th Gen. Intel Core™ i3 Processors, Intel Celeron, Intel Pentium
  • Intel C242 chipset
  • Up to 128GB ECC UDIMM, up to DDR4-2666MHz; 4 DIMM slots
  • 1 PCI-E 3.0 x16 slot
  • 2x 3.5" or 3x 2.5" drive bays with optional converter kits
  • M.2 Interface: 1 PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
  • 4 GbE LAN ports, 1 dedicated IPMI LAN
  • 2 USB 3.1 (rear), 2 USB 2.0 (rear)
  • 1 VGA, 1 COM, 1 TPM
  • 350W Multi-output power supply, Platinum Level Certified



Loading Configurator...

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Up To 50% More Cores

Powered by the latest Intel Xeon E family of processors, featuring up to 50% more cores than previous generation Xeon processors.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon E processor range, delivering massive improvements in every metric over the previous generation processors.

Data Protection Technology

Security is substantially improved with Intel Data Protection Technology (with Advanced Encryption Standard New Instructions).

Ideal For Small Business

Systems based on Intel Xeon E processors enable your business to evolve while also delivering a constantly available solution to safeguard your data.

Configure With Single Processor

Designed for server applications where multi processors are not required. Single processors are an affordable, cost-effective and reliable option.

Configure With Up to 128GB of RAM

Equipable with up to 128GB of RAM, this system optimised for light to mid level processing and offers a superb performance to cost ratio.

Entry Level Optimised Server

Perfect for smaller businesses, this server is optimised as an entry level server. The advantages of an entry level server include cost effectiveness.

Designed For Short Depth

Built for short depth, this server is very space efficient. Short Depth servers can be less than half the length of standard servers, perfect for situations where space is at a premium.

Configure With Fixed Drives

The Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L can be configured with reliable fixed drives which are a cheaper alternative to hot-swappable drives, lowering the overall cost of the system.

Configure with 2.5" Drives

The Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.

Integrated Quad Gigabit Ethernet

The integrated quad gigabit ethernet network adapter delivers performance and reliability. This server is free from vendor lock-in and features wide ranging hardware and software compatibility.


A 1U Supermicro SuperServer based on 1x Intel Xeon E-2100 range of processors, the Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L is configurable with up to 3x Fixed Drives drive bays, and designed for optimal performance with 4x 2666MHz DDR4 memory sockets .

The Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L supports the Intel Intel Xeon E 2100 Series , Intel Xeon E 2200 Series family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L boasts 1 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SYS-5019C-M4L SuperServer | 5019C-M4L Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: Xeon E-2100
  • Range: Entry Level Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Fixed Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 64GB
